- 500mm/s Printing Speed& 330*330*600mm Large Build Volume
- Hands-free fully automatic bed leveling and calibration
- Core-XY structure ensures rigidity and precision for stable, accurate prints
- Dual extruders simplify complex models with soluble supports
- 1-year warranty on printers, 3-months on extruder parts
Large Size,
Expanding Printing
Boundaries
Raft Support
Combining advantages of self-supporting and breakaway supports, it saves support printing time and enables effortless support removal.
Why is time saved?
The support is printed with the same material as the model, minimizing extruder switches and reducing waiting time.
High Surface Quality
Dual Z-axis ball screws ensure precision, while vibration suppression and controlled extrusion improve surface quality and detail.
What's More
Auto Shutdown Once Print Done
Safely print your models at night and pick them up during the day.
Power Loss Recovery
Avoid failed prints due to accidental power outages and guarantee normal printing
Filament Run-out Reminder
Automatically detect filament shortage and pause printing. Printing can be resumed after filament fed.
HEPA 13 Air Filtration System
Filter particles and odors for a safe, eco-friendly workspace
Specification
Machine Name
Guider 3 Ultra
Extruder Quantity
2
Printing precision
±0.15 mm or ±0.002 mm/mm (whichever is larger)
Position precision
X/Y-axis: 0.011 mm; Z-axis: 0.0025 mm
Layer thickness
0.05~0.4 mm
Build size
Single extruder: 330 × 330 × 600 mm; Dual extruders: 300 × 330 × 600 mm
Nozzle diameter
0.4 mm (Default); 0.6 / 0.8 mm (Optional)
Printing speed
10–500 mm/s
Max Acceleration
20000 mm/s²
Max travel speed
500 mm/s
Max extruder temperature
350℃
Filament type
PLA, ABS, HIPS, ASA, PETG, CoPA, PLA-CF, PETG-CF, PAHT-CF, PAHT-GF, PET-CF, PET-GF, PA12-CF, PA-CF, PA-GF, NexPA-CF25
Power supply
AC 100–240 V, 50/60 Hz, 850 W MAX
Device size
635 × 550 × 1070 mm (excluding the protruding width of the filament box)
Packaging size
775 (L) × 690 (W) × 1235 (H) mm
Gross weight
86 kg
Net weight
70 kg
Slicing software
Orca-Flashforge / FlashPrint 5
/
Input/Output file type
Input: 3MF, STL, OBJ, FPP, BMP, PNG, JPG, JPEG; Output: GX, G, Gcode
Printing connection
USB, Ethernet, Wi-Fi
Certification
CE / FCC / RoHS
Working temperature
15-30℃
/
Compatible operating system
Windows 7, Windows 8, Windows 10, Windows 11; Mac OS: support version 10.9 or later
Compatible slicing software
OrcaSlicer
Heating bed setting support
120
Close design
√
Auxiliary leveling
Full-auto one-click leveling
Filament running out reminding
√
Replaceable print bed
√
Continue last printing when power off
√
Intelligent door sensor
×
Touch LCD screen
7 Inch
Remote camera watching
√
Time-lapse video
√
Wireless WIFI
√
Ethernet
√
USB stick Interface
√
Air filter net
√
Magnetic Printing bed
Flexible Steel Plate Platform
Glass printing bed
×
Cloud
√
Noise
Silent Design
Automatic shutdown
√
